2.4. Evaluation Board
To help customers develop applications conveniently with EM120R-GL&EM160R-GL, Quectel supplies
the evaluation board (M.2 EVB), USB to RS-232 converter cable, USB type-C cable, earphone, antenna
and other peripherals to control or test the module. For more details, refer to document [2].
MIMO1 and MIMO2 antennas are only applicable to the EM160R-GL module.
NOTE
