Quectel LTE-A Module Series User Manual

LTE-A Module Series
EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 66 / 79
Pout might reduce in their values and exceed the specified tolerances. When the temperature returns
to the normal operating temperature level, the module will meet 3GPP specifications again.
6.5. Current Consumption
Table 38: EM120R-GL&EM160R-GL Current Consumption
6.6. RF Output Power
The following table shows the RF output power of EM120R-GL&EM160R-GL.
Table 39: RF Output Power
Parameter
Description
Conditions
Typ.
Unit
IVCC
OFF state
Power down
TBD
μA
Frequency
(Quectel SPEC)
Max.
Min.
WCDMA band 1, 3, 5, 8s
24 dBm +1.5/-3 dB
< -50 dBm
LTE-FDD band 1, 3, 5, 7, 8, 20, 28s
23 dBm ±2 dB
< -40 dBm
LTE-TDD band 38, 40, 41, 42, 43s
23 dBm ±2 dB
< -40 dBm
设置了格式
设置了格式: 字体: 五号
设置了格式: 字体: 五号
设置了格式: 字体: 五号
