EM120R-GL&EM160R-GL Hardware Design
EM120R-GL&EM160R-GL_Hardware_Design 12 / 79
EM120R-GL&EM160R-GL can be applied in the following fields:
⚫ Tablet PC and Laptop
⚫ Remote Monitor System
⚫ Vehicle System
⚫ Wireless POS System
⚫ Smart Metering System
⚫ Wireless Router and Switch
⚫ Other Wireless Terminal Devices
2.2. Key Features
The following table describes the detailed features of EM120R-GL&EM160R-GL.
Table 2: Key Features of EM120R-GL&EM160R-GL
carrier.
4.
4)
EM160R-GL supports up to 4 × 4 MIMO in DL direction.
5.
5)
MIMO antennas only apply for EM160R-GL.
6. For details about CA combinations, refer to document [1].
Feature
Details
Function Interface
PCI Express M.2 Interface
Power Supply
Supply voltage: 3.135–4.4 V
Typical supply voltage: 3.7 V
Transmitting Power
Class 3 (23 dBm ±2 dB) for LTE-FDD bands
Class 3 (23 dBm ±2 dB) for LTE-TDD bands
Class 3 (24 dBm +1/-3 dB) for WCDMA
LTE Features
EM160R-GL
Support up to LTE Cat 16
Support 1.4–100 MHz (5×CA) RF bandwidth
Support 4 × 4 MIMO in DL direction
Up to 1000 Mbps (DL)/150 Mbps (UL)
EM120R-GL
Support up to LTE Cat 12
Support 1.4–60 MHz (3×CA) RF bandwidth
Support 2 × 2 MIMO in DL direction
Up to 600 Mbps (DL)/150 Mbps (UL)
