6.7. RF Receiving Sensitivity
The following tables show conducted RF min. receiving sensitivity of EM120R-GL and EM160R-GL.
Table 40: EM120R-GL&EM160R-GL Conducted RF Min. Receiving Sensitivity
Frequency
Primary
Diversity
SIMO
1)
SIMO
2)
(Worst Case)
WCDMA B1
-111
-110
-110.5
-106.7 dBm
WCDMA B2
-109.5
-110
-110
-104.7 dBm
WCDMA B3
-109.5
-110.5
-111
-103.7 dBm
WCDMA B4
TBD
TBD
TBD
-106.7 dBm
WCDMA B5
-111
-111
-112
-104.7 dBm
WCDMA B6
TBD
TBD
TBD
-106.7 dBm
WCDMA B8
-111.5
-110.5
-111
-103.7 dBm
WCDMA B19
TBD
TBD
TBD
-106.7 dBm
LTE-FDD B1 (10 MHz)
-98
-98
-100.7
-96.3 dBm
LTE-FDD B2 (10 MHz)
-97.8
-97.7
-100.3
-94.3 dBm
LTE-FDD B3 (10 MHz)
-98.8
-97.3
-100.8
-93.3 dBm
LTE-FDD B4 (10 MHz)
-97.7
-97.9
-100.6
-96.3 dBm
LTE-FDD B5 (10 MHz)
-99.7
-99
-102
-94.3 dBm
LTE-FDD B7 (10 MHz)
-96
-97.2
-99.4
-94.3 dBm
LTE-FDD B8 (10 MHz)
-99
-99.2
-101.7
-93.3 dBm
LTE-FDD B12 (10 MHz)
-99.8
-99.5
-102.3
-93.3 dBm
LTE-FDD B13 (10 MHz)
-100.2
-99.4
-102.5
-93.3 dBm
LTE-FDD B14 (10 MHz)
-99.2
-99.2
-101.8
-93.3 dBm
LTE-FDD B17 (10 MHz)
-99.9
-99.6
-102.3
-93.3 dBm
LTE-FDD B18 (10 MHz)
-99.6
-99.4
-102.2
-96.3 dBm
