Quectel LTE-A Module Series - Page 81

FCC KDB996369 D03v01 Requirements
List of applicable FCC rules
FCC Part 15 Subpart B, Part 22 Subpart H, Part 24 Subpart E, Part 27 Subpart D & L & H & F
& M & N, Part 90 Subpart R & S, Part 96
Summarize the specific operational use conditions
Not Applicable
Limited module procedures
Not Applicable
Trace antenna designs
Refer to Manual Section 4
RF exposure considerations
Refer to FCC certification requirements
Antennas
Technology
Frequency Range
(MHz)
Antenna Type
Max Peak Gain (dBi)
WCDMA & LTE Band 2
1850 ~ 1910
Dipole
1.15
WCDMA & LTE Band 4
1710 ~ 1755
-0.50
WCDMA & LTE Band 5
824 ~ 849
1.85
LTE Band 7
2500 ~ 2570
1.32
LTE Band 12
699 ~ 716
-2.43
LTE Band 13
777 ~ 787
-0.10
LTE Band 14
788 ~ 798
2.40
LTE Band 25
1850 ~ 1915
1.15
LTE Band 26
814 ~ 849
1.85
LTE Band 30
2305 ~ 2315
-3.64
LTE Band 38
2570 ~ 2620
0.93
LTE Band 41
2496 ~ 2690
0.93
LTE Band 48
3550 ~ 3700
-3.37
LTE Band 66
1710 ~ 1780
-0.50
Label and compliance information
Refer to FCC Label
Information on test modes and additional testing requirements
Not Applicable
