Quectel RG520N-AT - Power Consumption

5G Module Series
RG520N-AT_Hardware_Design 84 / 109
6.3. Power Consumption
Table 48: Power Consumption
values.
USB_VBUS
USB connection detect
3.3
5.0
5.25
V
Mode
Conditions
Band/Combinations
Current
Unit
Power-off
Power off
-
150
μA
RF Disabled
AT+CFUN=0 (USB 3.0 suspend)
-
4
mA
AT+CFUN=4 (USB 3.0 suspend)
-
4.1
mA
Sleep State
SA FDD PF = 64 (USB 3.0 suspend)
-
9.3
mA
SA TDD PF = 64 (USB 3.0 suspend)
-
9.3
mA
Idle State
SA PF = 64 (USB 2.0 active)
-
40
mA
SA PF = 64 (USB 3.0 active)
-
60
mA
LTE
LTE LB @ 23 dBm
B5
TBD
mA
LTE MB @ 23 dBm
B2
TBD
mA
LTE HB @ 23 dBm
B30
TBD
mA
LTE CA
DL 3CA, 256QAM
CA_2A-5A-66A
TBD
mA
UL 1CA, 256QAM
Tx power @ 23 dBm
5G SA
(1 Tx)
5G NR LB @ 23 dBm
n12
TBD
mA
5G NR MB @ 23 dBm
n66
TBD
mA
5G NR HB @ 23 dBm
n30
TBD
mA
5G NR UHB @ 26 dBm
n77
TBD
mA
5G SA
(2 Tx)
5G NR UL 2 × 2 MIMO @ 26 dBm
n77
TBD
mA
