Table 51: (U)SIM 2.95 V I/O Requirements
6.5. ESD Protection
Static electricity occurs naturally and it may damage the module. Therefore, applying proper ESD
countermeasures and handling methods is imperative. For example, wear anti-static gloves during the
development, production, assembly and testing of the module; add ESD protection components to the
ESD sensitive interfaces and points in the product design.
Table 52: Electrostatics Discharge Characteristics (Temperature: 25–30 °C, Humidity: 40 ±5 %)
V
OL
Output low voltage
-
0.4
V
Parameter
Description
Min.
Max.
Unit
USIM_VDD
Power supply
2.7
3.05
V
V
IH
Input high voltage
2.06
3.25
V
V
IL
Input low voltage
-0.3
0.59
V
V
OH
Output high voltage
2.36
-
V
V
OL
Output low voltage
-
0.4
V
Tested Interfaces
Contact Discharge
Air Discharge
Unit
VBAT, GND
±5
±10
kV
All Antenna Interfaces
±4
±8
kV
Other Interfaces
±0.5
±1
kV
