10.3 Coffee unit cleaning
• Unscrew the assembly screw anti-clockwise with an Allen key (1).
• Once unscrewed, remove the hand shower sprayer, taking care not to lose
the spring inside.
• You can now remove the hand shower (2) and the hand shower support disc
(3).
• Remove the gaskets (4) and (5) paying attention to the assembly sequence.
• Clean the gasket seat with the supplied brush and insert the new gasket.
• Reassemble all parts following the disassembly sequence backwards.
1
2
3
4
5
