2. MACHINE COMPONENTS AND FUNCTIONING
2.1 General characteristics
The machine has been designed and built to supply coffee, water and steam. It
has no grinder.
On the right side there is a compartment for the insertion of the water tank.
The buttons on the front are used to distribute the drinks and to program the
machine functions.
Inside the machine, the exchanger is located for heating water and steam and
the exchanger for coffee.
The parts that make up the machine are described below.
Key:
a. Support feet
b. Filter holder
c. Coffee delivery group
d. Display
e. Hot water supply button
f. Steam release button
g. Coffee dispense button
h. Pressure gauge
i. Water tank
j. Drip tray
k. Steam lance / hot water
l. Profiling valve
m. Steam dispensing tap
n. Cup-warmer top
o. Machine ignition switch
p. Power connection socket
Dimensions l x p x h 255 x 333 x h 382 m
Net weight 16 Kg
Power supply 110/240 V / 50-60 Hz
Power 1260 W
Working temperature +5° / +45° C
