Section III - Airlogic Graphic Controller
Text on figures
(i) Inlet pressure
(ii) Flow
(iii) Off, Shutdown,... (text varies upon the vacuum pumps actual condition)
(iv) Menu
(v) Discharge pressure
(vi) Element outlet
(vii) vacuum control, purge, preparing to go online,...(text varies upon the vacuum pumps
actual condition)
• Section A shows information regarding the vacuum pump operation (e.g. the Inlet
pressure or the temperature at the vacuum pump outlet). On Vacuum pumps with a
frequency converter, the load degree (ow) is given in % of the maximum ow at the
actual inlet pressure.
• Section B shows Status icons. Following icon types are shown in this field:
• Fixed icons
These icons are always shown in the main screen and cannot be selected by the
cursor (e.g. vacuum pump stopped or running, vacuum pump status (running,
running unloaded or motor stopped).
• Optional icons
These icons are only shown if their corresponding function is activated (e.g. week
timer, automatic restart after voltage failure , etc.)
• Pop up icons
These icons pop up if an abnormal condition occurs (warnings, shutdowns,
service,...) To call up more information about the icons shown, select the icon
concerned using the scroll keys and press the enter key..
• Section C is called the Status bar
This bar shows the text that corresponds to the selected icon.
• Section D shows the Action buttons. These buttons are used:
• To call-up or program settings
• To reset a motor overload, service message or emergency stop
• To have access to all data collected by the regulator
The function of the buttons depends on the displayed menu. The most common
functions are:
Designation Function
Menu To go to the menu
Modify To modify programmable settings
Reset To reset a timer or message
To activate an action button, highlight the button by using the Scroll keys and press
the Enter key. To go back to the previous menu, press the Escape key.
Quincy Vacuum Pump-QSV Series 23
