Section III - Airlogic Graphic Controller
Function
• To display the actual value of the measured data (analog inputs) and the status of the
digital inputs (e.g. emergency stop contact, motor overload relay, etc.).
• To select the digital input to be shown on the chart in the main screen.
Procedure
Starting from the Main screen (see Main screen):
• Move the cursor to the action button Menu and press the enter key, following screen
appears:
Text on figures
(1) Menu
(2) Regulation
• Using the scroll keys, move the cursor to the inputs icon (see above, section Menu
icon)
• Press the enter key, a screen similar to the one below appears:
Quincy Vacuum Pump-QSV Series 27
