R&S NRP8S User Manual

Browser-Based User Interface
R&S
®
NRPxxS(N)
42User Manual 1177.5079.02 ─ 10
6.2 Setting the Unit
You can set the unit for the different parameters by typing the corresponding letter after
the entered value.
Figure 6-2: Parameter
1 = Parameter name
2 = Value
3 = Unit
The following abbreviations are available:
Unit Keyboard key
Decibel d
Hertz h
Second s
Volt v
Watt w
Unit multiples Keyboard key
Giga g
Mega m
Kilo k
milli m
micro u
nano n
Example:
To set the unit to 1 GHz, enter 1g.
For certain units, you can select a different representation, depending on the require-
ments. For example, for the representation of the "Trigger Level", you can choose
Watt, dBm or dBµV. To change the unit, you must specify the desired value together
with the full new unit once.
Setting the Unit
