R&S NRP8S User Manual

Remote Control Commands
R&S
®
NRPxxS(N)
92User Manual 1177.5079.02 ─ 10
Example: The following sequence of commands configures a Peak Trace
measurement
*RST
SENSe:FUNCtion "XTIMe:POWer"
SENSe:FREQuency 1.0e9
SENSe:TRACe:POINts 500
SENS:TRAC:TIME 20e-3
TRIGger:SOURce INTernal
TRIGger:SLOPe POSitive
TRIGger:DTIMe 0.001
TRIGger:HYSTeresis 0.1
TRIGger:LEVel 30e-6
SENSe:TRACe:AVERage:COUNt 8
SENSe:TRACe:AVERage:STATe ON
CALCulate:FEED "POWer:PEAK:TRACe"
INITiate
FETCh?
[SENSe<Sensor>:]AUXiliary <mode>
Enables the measurement of additional measured values that are determined together
with the main measured value.
Parameters:
<mode> NONE | MINMax | RNDMax
NONE
No additional values are measured.
MINMax
Minima and maxima of the trace are transmitted together with
the measured value.
Usually, extreme values are lost due to averaging the measured
values.
RNDMax
Randomly selected samples are transmitted. All evaluations use
these values instead of the average values.
*RST:
NONE
9.7 Configuring the Measurement Modes
In the following chapter the settings needed for configuring a measurement mode are
described.
Further information:
●
Chapter 9.8, "Configuring Basic Measurement Parameters", on page 104
●
Chapter 9.5, "Controlling the Measurement", on page 72
Contens:
Configuring the Measurement Modes
