Remote Control Commands
R&S
®
NRPxxS(N)
83User Manual 1177.5079.02 ─ 10
Example: See Chapter 10.3, "Performing a Buffered Continuous Average
Measurement", on page 146.
TRIGger:DELay <delay>
Sets the delay between the trigger event and the beginning of the actual measurement
(integration).
Parameters:
<delay> Range: -5.0 to 10.0
*RST: 0.0
Default unit: s
Manual operation: See "Trigger Delay" on page 54
TRIGger:DELay:AUTO
<state>
If TRIGger:DELay:AUTO ON is set, no measurement is started until the power sensor
has settled. For this purpose, the delay value is automatically determined.
If a longer period is set using TRIGger:DELay, the automatically determined delay is
ignored.
Parameters:
<state> *RST: OFF
TRIGger:DTIMe <dropout_time>
Sets the dropout time for the internal trigger source. During this time, the signal power
must exceed (negative trigger slope) or undercut (positive trigger slope) the level
defined by the trigger level and trigger hysteresis. At least, this time must elapse before
triggering can occur again.
See Chapter 9.5.2.4, "Dropout Time", on page 75.
Parameters:
<dropout_time> Range: 0.00 to 10.00
*RST: 0.00
Default unit: s
Manual operation: See "Dropout" on page 54
TRIGger:EXTernal<2...2>:IMPedance <impedance>
Effective only if TRIGger:SOURce EXTernal2 is set.
Sets termination resistance of the second external trigger input. Choose the setting
that fits the impedance of the trigger source to minimize reflections on the trigger sig-
nals.
Controlling the Measurement
