Remote Control Commands
R&S
®
NRPxxS(N)
72User Manual 1177.5079.02 ─ 10
See also Chapter 9.7.1, "Continuous Average Measurement", on page 93.
●
Burst average ("POWer:BURSt:AVG"): The integration time of a measurement is
not predefined but determined by the sensor with the aid of a burst detector. The
start of a burst is detected when the measurement signal rises above a set trigger
level. The measurement ends when the signal drops below a trigger threshold.
See also Chapter 9.7.2, "Burst Average Measurement", on page 96.
●
Timeslot average ("POWer:TSLot:AVG"): The power is simultaneously measured
in up to 32 time slots. The measurement result is represented by a vector that can
contain up to 32 indices and contains the power of a time slot at each index.
See also Chapter 9.7.3, "Timeslot Average Measurement", on page 97.
●
Trace ("XTIMe:POWer"): A sequence of measurements is performed.
See also Chapter 9.7.4, "Trace Measurement", on page 99.
9.5 Controlling the Measurement
The power sensor offers a bunch of possibilities to control the measurement:
●
Do you want to start the measurement immediately after the initiate command or
do you want to wait for a trigger event?
●
Do you want to start a single measurement cycle or a sequence of measurement
cycles?
●
Do you want to output each new average value as a measurement result or do you
want to bundle more measured values into one result?
9.5.1 Starting and Ending a Measurement
ABORt............................................................................................................................ 72
INITiate:ALL.................................................................................................................... 73
INITiate[:IMMediate]......................................................................................................... 73
INITiate:CONTinuous........................................................................................................73
ABORt
Immediately interrupts the current measurement. If the measurement has been started
as a single measurement (INITiate[:IMMediate]), the sensor goes into the idle
state. However, if a continuous measurement is in progress (INITiate:CONTinuous
ON), the trigger system of the sensor enters the waiting for trigger state, and if the trig-
ger condition is met, a new measurement is immediately started.
See also Chapter 9.5, "Controlling the Measurement", on page 72.
Usage:
Event
Controlling the Measurement
