Remote Control Commands

R&S

NRPxxS(N)

71User Manual 1177.5079.02 ─ 10

Remote commands:

[SENSe<Sensor>:]RANGe................................................................................................71

[SENSe<Sensor>:]RANGe:AUTO......................................................................................71

[SENSe<Sensor>:]RANGe:CLEVel....................................................................................71

[SENSe<Sensor>:]RANGe <range>

Selects the active measurement path manually.

Parameters:

<range> The sensitivity of the paths differs.

0 is the most sensitive path.

2 is the most insensitive path.

1 is the path with medium sensitivity.

Range: 0 to 2

*RST: 2

Manual operation: See "Range" on page 49

[SENSe<Sensor>:]RANGe:AUTO <state>

Enables automatic measurement path selection.

Parameters:

<state> *RST: ON

Manual operation: See "Range" on page 49

[SENSe<Sensor>:]RANGe:CLEVel <level>

Reduces the transition range between the measurement paths, 0 -> 1 and 1 -> 2, by

the set value. Thus, you can improve the measurement accuracy for signals with a

high peak-to-average ratio, since the headroom for modulation peaks becomes larger.

However, the S/N ratio is reduced at the lower limits of the transition ranges.

Parameters:

<level> Range: -20.00 to 0.00

*RST: 0.00

Default unit: dB

9.4.3 Selecting a Measurement Mode

► Before starting a measurement, select the measurement mode using:

[SENSe<Sensor>:]FUNCtion

The following modes are available:

●

Continuous average ("POWer:AVG"): After a trigger event, the power is integrated

over a time interval.

Preparing for the Measurement
