Remote Control Commands
R&S
®
NRPxxS(N)
85User Manual 1177.5079.02 ─ 10
TRIGger:LEVel <level>
Effective only if TRIGger:SOURce INTernal.
Sets the trigger threshold for internal triggering derived from the test signal.
If you enter a value without unit, the unit is defined by TRIGger:LEVel:UNIT.
If an S-parameter device is active and/or if a mounted component with a global offset
in front of the sensor is considered, the currently effective trigger threshold and a trig-
ger threshold to be input are referenced to the appropriately shifted sensor data. If the
S-parameter device and/or the offset correction are disabled, the trigger threshold and
its input limits are adjusted as necessary.
Parameters:
<level> Range: 1.0e-7 to 200.0e-3
*RST: 1.0e-6
Default unit: Watts
Manual operation: See "Trigger Level" on page 54
TRIGger:LEVel:UNIT <unit>
Sets the unit of the trigger level if this value is entered without a unit.
See also TRIGger:LEVel on page 85.
Parameters:
<unit> DBM | W | DBUV
*RST: W
Manual operation: See "Trigger Level" on page 54
TRIGger:MASTer:PORT <master_port>
Selects the port where the sensor outputs its own trigger event in case it is trigger mas-
ter. See TRIGger:MASTer:STATe for more information.
If the sensor is the trigger master, it can output its trigger event either on the
EXTernal<1> or EXTernal2.
If the sensor triggers itself, the trigger source of the sensor must be assigned to the
other external port, as shown in the examples.
Parameters:
<master_port> EXT1 | EXTernal1 | EXT2 | EXTernal2
*RST: EXT1
Example:
TRIG:MAST:PORT EXT1
TRIG:SOUR EXT2
TRIG:MAST:STAT ON
Example:
TRIG:MAST:PORT EXT2
TRIG:SOUR EXT1
TRIG:MAST:STAT ON
