Remote Control Commands
R&S
®
NRPxxS(N)
99User Manual 1177.5079.02 ─ 10
Manual operation: See "Number of Timeslots" on page 46
[SENSe<Sensor>:][POWer:]TSLot[:AVG]:WIDTh <width>
Sets the length of the timeslot (see Figure 9-3).
Parameters:
<width> Range: 10.0e-6 to 0.10
*RST: 1.000e-3
Default unit: Seconds
Manual operation: See "Nominal Width" on page 47
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:OFFSet[:TIME]
<time>
Determines the distance from the start of the timeslots to the start of the interval to be
blanked out (see Figure 9-3).
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID:TIME <time>
Sets the length of the time interval in the timeslots to be excluded from the measure-
ment (see Figure 9-3). The parameter applies to each individual timeslot.
Note: Even if the exclusion interval exceeds the timeslot because, for example, its right
limit is outside the timeslot, correct results are obtained. In the extreme case, where
the interval length has been set to a value greater than the timeslot length, 0 W is out-
put as the measured power. No error message is output.
Parameters:
<time> Range: 0.00 to 0.10
*RST: 0.00
Default unit: Seconds
[SENSe<Sensor>:][POWer:]TSLot[:AVG][:EXCLude]:MID[:STATe] <state>
Enables or disables the blanking out of time intervals in the timeslots.
Parameters:
<state> *RST: OFF
9.7.4 Trace Measurement
The trace measurement is used to acquire the course of power over a certain time.
During the measurement time ([SENSe<Sensor>:]TRACe:TIME) a large number of
measurements are made and the result is returned to the user as an array of values
Configuring the Measurement Modes
