Remote Control Commands

R&S

NRPxxS(N)

97User Manual 1177.5079.02 ─ 10

[SENSe<Sensor>:]TIMing:EXCLude:STARt and [SENSe<Sensor>:]TIMing:

EXCLude:STOP on page 109, see Chapter 9.8.3, "Setting Exclusion Time",

on page 109.

Remote commands:

[SENSe<Sensor>:][POWer:]BURSt:DTOLerance................................................................ 97

[SENSe<Sensor>:][POWer:]BURSt:LENGth?..................................................................... 97

[SENSe<Sensor>:][POWer:]BURSt:DTOLerance <tolerance>

Sets the drop-out tolerance, a time interval in which the pulse end is only recognized if

the signal level no longer exceeds the trigger level (see Figure 9-2).

Parameters:

<tolerance> Range: 0.00 to 0.30

*RST: 1.000e-6

Default unit: Seconds

Manual operation: See "Dropout Tolerance" on page 46

[SENSe<Sensor>:][POWer:]BURSt:LENGth?

Queries the length of a burst (pulse interval), the time between the trigger point of the

measurement and the time the trigger logic detects the end of the pulse (see Fig-

ure 9-2).

Usage:

Query only

9.7.3 Timeslot Average Measurement

The Timeslot Average mode is used to measure the average power of a definable

number of successive timeslots within a frame structure with equal spacing. The mea-

surement result is an array with the same number of elements as timeslots. Each ele-

ment represents the average power in a particular timeslot.

Fig.9-3 shows a graphical representation of a timeslot average measurement and the

meaning of the parameters that can be configured.
