3. On the Slave camera(s), follow the instructions below:
A.
Go to Menu > Settings > Setup > Communication.
B.
Type a name for the camera (Example: CAM B, RIGHT, SLAVE, etc) in the Camera ID field.
C.
For Target, select None.
Figure: Slave Settings
D.
Go to Menu > Settings > Setup > Communication and select the Ethernet tab.
E.
Select the Camera to Camera the check box.
The LAN indicator in the Lower Status Row illuminates green.
NOTE: Cameras can also be set up in a Master/Master configuration. To set up Master/Master, set Target to All
on both cameras, allowing either camera to make changes and control record start/stop.
REQUIRED CABLE
790-0163: Master/Slave Gig-E Cable (4')
