MONITOR CONFIG (MONITOR CONFIGURATION)
Use the Monitor Config menu to apply looks and curves to the monitor outputs.
1. Select the monitor to configure from the drop-down menu at the top of the menu.
2.
Select a look from the Look drop-down menu. Looks are set up in the Look Config menu. For more information,
go to "Look Config (Look Configuration)" on the previous page.
3.
Select a curve from the Curve drop-down menu:
Neutral: The camera does not apply a graded gamma space to the monitor output.
Graded: The camera applies a graded gamma space to the monitor output.
The Video Path displays the video source and graded gamma space applied to the monitor.
NOTE: The Curve drop-down menu is available if the Video Source is set to RLF or ACES. For more information,
go to "Video" on page89.
Figure: Monitor Config
