Ellipse INSTALLATION GUIDELINES
70-00159-01-09 Proprietary Redline Communications © 2015 Page 25 of 52 April 29, 2015
3.5 Environmental Conditions (Cabinet/Shelter)
The equipment cabinet must protect the in-cabinet equipment.
Figure 13: Site Survey: Cabinet Equipment
Table 10: Site Survey: Operating Temperature Range
Ellipse
Ellipse-ER
Outdoor
-40 to 75 °C (-40 to 167 °F)
PoE
In-cabinet
-40 to 75 °C (-40 to 167 °F)
Surge
Suppression
In-cabinet
-40 to 85 °C (-40 to 185 °F)
