Ellipse INSTALLATION GUIDELINES
70-00159-01-09 Proprietary Redline Communications © 2015 Page 29 of 52 April 29, 2015
4 Installation Procedures
This section describes installation of the Ellipse wireless sector controller, PoE power
injector and surge suppression device. The installer will need to complete the following
activities as part of the installation procedure for the Ellipse radio.
4.1 Preparation
1. System installation overview
2. Materials supplied by installer
3. Site Survey
4.2 Configure System Operating Parameters
1. Setup test bench
2. Login with test PC
3. Restore default settings
4. Install Options Key(s)
5. Required Network and RF settings
6. Change Passwords
4. 3 Install Outdoor Equipment
1. Attach sector controller to antenna
2. Connect Ethernet and antenna cables (RF + GPS)
3. Assemble antenna mounting bracket.
4. Mount the sector controller on mast
5. Align antenna
4.4 Install In-Cabinet Equipment
1. Install PoE power injector
2. Install Ethernet surge arrestor
