Reer MOSAIC M1S Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
10 8540780 • 10/07/2020 • Rev.38
English
OVERVIEW
MOSAIC is a modular safety controller. It consists of a master unit (M1 or M1S),
which can be configured using the MSD graphic interface, and a number of
expansion units connected to the main unit via the proprietary MSC bus.
The M1 or M1S can also be used as a stand-alone device and they are equipped
with:
 M1: 8 safety inputs, 2 independent programmable dual channel safety
outputs (OSSD) and 2 SIL 1/PL c outputs
 M1S: 8 safety inputs, 4 independent programmable single channel safety
outputs (OSSD) and up to 4 SIL 1/PL c outputs

The following expansions are available: I/O expansions (MI8O2 and MI8O4(with M1S
only)), input expansions (MI8, MI12T8, MI16), output expansions (MO2, MO4 and
MO4LHCS8 and MO4L (only for M1S)), SIL 1/PL c output expansions (MOS8 and
MOS16), guided contact safety relay output modules (MR2, MR4, MR8, MOR4 and
MOR4S8), encoder and proximity input expansions (MV2, MV, MV0), modules with
analog inputs (MA2, MA4 only for M1S) and diagnostic connections to the main
fieldbuses: MBP (PROFIBUS), MBC (CanOpen), MBD (DeviceNet), MBEI (ETHERNET/IP),
MBEP (Profinet), MBEC (ETHERCAT), MBMR (Modbus RTU), MBEM (Modbus/TCP)
MBCCL (CC-link).
MOSAIC is capable of monitoring the following safety sensors and commands:
optoelectronic sensors (safety light curtains, scanners, safety photocells),
mechanical switches, safety mats, emergency stops, two-hand controls, all
managed by a single flexible and expandable device.
The system must consist of just one Master M1 or M1S and a number of electronic
expansions that can range from 0 to a maximum of 14, not more than 4 of which
of the same type. There is no limit to the number of relay modules MR2 e MR4 that
can be installed.
With 14 expansions, the system can have up to:
 with M1: 128 inputs, 16 safety outputs and 32 SIL 1/ PL c outputs.
 with M1S: 128 inputs, 32 safety outputs and 48 SIL 1/ PL c outputs.
MASTER and its SLAVE units communicate via the 5-way MSC bus (ReeR proprietary
bus), physically arranged on the rear panel of each unit.
Furthermore, by means of MBx Fieldbus interfaces, are available:
 All inputs states (with diagnostics)
 All safety outputs states (with diagnostics)
 8 fieldbus inputs with M1 or 32 fieldbus inputs with M1S (MBx firmware
2.0). These fieldbus inputs can act in the schematic as physical
inputs, but are not safety inputs and they can
applications.
 16 probe outputs with M1 or 32 probe outputs with M1S (MBx firmware
These probe outputs can be connected everywhere in the
schematic by means of MSD software.

Reer MOSAIC M1S Specifications

General

Brand	Reer
Model	MOSAIC M1S
Category	Controller
Language	English
