MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 35
SIGNALS
INPUTS
MASTER ENABLE
The MOSAIC M1 master has two inputs: MASTER_ENABLE1 and MASTER_ENABLE2.
These signals must both be permanently set to logic level 1 (24VDC) for the MOSAIC
to operate. If the user needs to disable the MOSAIC simply lower these inputs to logic
level 0 (0VDC).
These input are not present on M1S which is always enabled.
NODE SEL
The NODE_SEL0 and NODE_SEL1 inputs (on the SLAVE units) are used to attribute a physical
address to the slave units with the connections shown in Table 23:
Table 23
A maximum of 4 addresses is provided and 4 modules of the same type can be used in the
same system.
It is not allowed to use the same physical address on two units of the same type.
In order to be used, the expansion units must be addressed at the time of installation
(see the NODE SEL section).
