MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
104 8540780 • 10/07/2020 • Rev.38
ged during the monitor. It is possible to display the
parameters of a component by clicking on it with the right mouse button, choosing
"Show/Hide Properties".
Figure 67 - graphical monitor
Password protection
The MSD requests a password in order to upload and save the project.
The password entered as default must be modified to avoid manipulation (level 2
password) or so that the configuration loaded on Mosaic (level 1 password) is not
visible.
Level 1 password
All operators using the M1/M1S system must have a Level 1 PASSWORD.
This password allows only to view the configuration and error LOGs, composition of the
system and MONITOR in real time and upload operations.
For the first time the password is "" (ENTER key).
Designers who know the level 2 password can enter a new level 1 password
(alphanumerical, max 8 characters).
Operators who know this password are enabled to upload (from M1/M1S to PC),
modify or save the project.
