MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 105
Level 2 password
Designers authorised to work on the creation of the project must know a Level 2
PASSWORD. The first time the system is initialised the operator must use the password
"SAFEPASS" (all capital letters).
Designers who know the level 2 password can enter a new level 2 password
(alphanumerical, max 8 characters).
With the Level 2 password, the designers authorized has availabele all the functions of Level
plus the ability to downoad the project from PC to Mosaic and change the passwords

This password enables the project to be uploaded (from PC to M1), modified and
saved. In other words, it allows total control of the PC => MOSAIC system.

When a new project is UPLOADED the level 2 password could be changed.

Should you forget either of these passwords, please contact ReeR which will provide
an unlock file (when the unlock file is saved in the right directory the icon will
appear on the toolbar). When the icon is activated, the password level 1 and level 2
are restored to their original values. This password is only given to the designer and
can only be used once.
Password Change
To activate the PASSWORD Change use icon , after connecting with Level 2 Password.
A window appears (Figure 68) allowing the choice of the new password; insert the old and
new passwords in the appropriate fields (max 8 characters). Click OK.
At the end of the operation disconnect to restart the system.
If MCM is present the new password is also saved in it.
Figure 68
