Reer MOSAIC M1S Installation And Use

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
52 8540780 • 10/07/2020 • Rev.38
English
MA2, MA4 module
Module
MA2
MA4
PFH
d
(IEC 61508:2010)
9,54E-09
1,53E-8
Rated voltage
24 VDC  20%
24 VDC  20%
Max dissipated power
3W
5W
Channels number / description
2 / fully isolated (500 VDC)
Each channel can be configured as
Voltage input or Current input
4 / fully isolated (500 VDC)
Each channel can be configured as
Voltage input or Current input
Current output sensors
Range
4...20 mA (0‐20 mA)
Conversion bits
16
Resolution (minimum current
variation relevable)
381 Na
Sample rate (Samples per second)
User selectable. Allowable values:
2.5, 5, 10, 16.6, 20, 50, 60, 100,
200, 400, 800, 1000, 2000, 4000
Conversion internal resistance
200 Ohm
Max input current
23 mA
Voltage output sensors
Range
0...10 VDC
Conversion bits
16
Resolution (minimum voltage
variation relevable)
152 uV
Sample rate (Samples per second)
User selectable. Allowable values:
2.5, 5, 10, 16.6, 20, 50, 60, 100,
200, 400, 800, 1000, 2000, 4000
Conversion internal resistance
250 kOhm
Diagnostic
Isolated sensor power supply
overload (if the sensor draws more
than 30 mA)
YES with active protection.
When this condition is detected the power supply of the sensor is disconnected for
1 second and then again activated to check if the overload condition still exist in
an endless loop until the overload condition disappear.
Input overvoltage / input
overcurrent
YES with active protection.
When this condition is detected the power supply of the sensor is disconnected for
1 second and then again activated to check if the input overvoltage/overcurrent
condition still exist in an endless loop until the anomaly disappear.
Disconnected cable detection
YES
Overthreshold / Underthreshold
detection
YES
Connection to M1S
via MSC 5-way ReeR proprietary bus
