MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 10/07/2020 • Rev.38 89
MOSAIC SAFETY DESIGNER SOFTWARE
The "MOSAIC SAFETY DESIGNER" application software can be used to configure a logic
diagram of the connections between the MOSAIC (Master + expansions) and the
components of the system being developed.
The MOSAIC and its SLAVE units will thus monitor and control the connected safety
components.
The MSD uses a versatile graphic interface to establish the connections between the various
components, as described below:
Installing the software
PC HARDWARE requirements
• RAM: 256 MB (minimum to run 7 with Service Pack 1 + Framework 4.0)
•
• USB port: 2.0 or greater
• Internet connection for program download
• CD-ROM drive
PC SOFTWARE requirements
• Windows 7 with Service Pack 1 installed (or higher OS).
• Microsoft Framework 4.0 (or higher) must be installed on the PC
Installation of MSD software
• Insert the installation CD;
• Wait for the auto-run installer to request the SW setup program;
• Otherwise, run the file located on the root of the installation CD or
download the last available version from the Download section of the ReeR website:
https://www.reersafety.com/it/en/download/configuration-software.
When the installation procedure is complete a window is displayed asking you to close
the setup program.
