1.6. Weight
REMS Multi-Push SL 36.7 kg (81 lb)
REMS Multi-Push SLW 39.0 kg (86 lb)
1.7. Noiseinformation
Work place-related
Emission value L
PA = 73 dB(A); L WA = 92 dB(A); K = ± 1 dB
2. Start-up
CAUTION
 Transportweightsabove35kgmustbecarriedbyatleast2persons.
2.1. Electrical connection
WARNING
Caution: Mains voltage present! Before connecting the electronic ushing and
pressure testing unit, check whether the voltage given on the rating plate corre
-
sponds to the mains voltage. Only use sockets/extension leads with a functioning
PE contact. The function of the PRCD fault current circuit breaker (Fig. 1 (1))
must be checked every time before start-up and before beginning work:
1. Plug the mains plug into the socket.
2. Press the RESET button (2), the PRCD control lamp (Fig. 1 (39)) lights red
(operating state).
3. Pull out the mains plug, the PRCD control lamp (39) must go out.
4. Plug the mains plug back into the socket.
5. Press the RESET button (2), the PRCD control lamp (39) lights red (oper
-
ating state).
6. Press the TEST button (3), the PRCD control lamp (39) must go out.
7. Press the RESET button (2) again, the PRCD control lamp (39) lights red.
The control lamp (Fig. 2 (5)) lights green. REMS Multi-Push is ready for
operation after about 10 s.
WARNING
If the described functions of the PRCD fault current circuit breaker (Fig. 1 (1))
are not fullled, the device may not be used. There is a danger of electric shock.
The PRCD fault current circuit breaker tests the connected device, not the
installation before the socket nor interconnected extension leads or cable reels.
On building sites, in a wet environment, indoors and outdoors or under similar
installation conditions, only operate the electronic ushing and pressure testing
unit on the mains with a fault current protection switch (FI switch) which interrupts
the power supply as soon as the leakage current to earth exceeds 30 mA for
200 ms. A cable cross-section that corresponds to the power of the electronic
ushing and pressure testing unit must be selected when using an extension
lead.
Press the On/Off button on the input and control unit's operating panel (Fig. 2
(4)) for approx. 2 s, then release it. REMS Multi-Push is switched on and the
compressor switches on. The screen (6) is illuminated and the REMS Multi-
Push logo appears followed by the start menu:
Flushing
Disinfection
Testing
Compressed Air Pump
Memory Manager
2.2. Menu structure and on-screendisplays
Five main programs of the REMS Multi-Push are displayed in the Start menu:
Flushing, Disinfection, Testing, Compressed Air Pump, Memory Manager. The
screen display contains a maximum 5 lines with 20 characters each. Lines with
defaults or test values are displayed language-independently with physical
formula symbols, a uniform verbal abbreviation and the value of the test crite
-
rion in the sub-routines. These have the following meanings:
p refer bar xxx reference test pressure bar
p refer mbar xxx reference test pressure mbar
p actual bar xxx actual test pressure bar
p actual mbar xxx actual test pressure mbar
p diff bar xxx differential test pressure bar
p diff mbar xxx differential test pressure mbar
t stabi min xxx stabilisation/wait time min
t test min xxx test time min
Δ > 10K difference >10°C (10 Kelvin) water/environment
PfS press tting system (ZVSHK)
P+M load test plastic + metal
p H 2 O bar water pressure
v H 2 O m/s minimum ow speed
t H 2 O min ushing time
n H 2 O n-times water change
VA H 2 O l volume of the ushing section
VS H 2 O l/min volume ow
V H 2 O l used water volume
File no. memory location no. for measuring log
max. DN largest rated diameter
Enter next screen display
Esc previous screen display or cancel
Ver. Software version software
2.3. Settingsmenu
NOTICE
The defaults for the different test criteria in the settings menu of the REMS
Multi-Push are taken from EN 806-4:2010 or the information leaet "Leak tests
of drinking water installations with compressed air, inert gas or water" (January
2011) of the German Central Association for Sanitary, Heating and Air Condi
-
tioning (ZVSHK). All defaults for the test programs can be edited by the user
in the Settings menu and in the Flushing, Test with compressed air, Test with
water and Compressed Air Pump programs. Changes in the Settings menu are
saved, i.e. they reappear the next time the REMS Multi-Push is switched on.
If the defaults are only changed in one of the programs, the original defaults
appear again the next time the REMS Multi-Push is switched on. Reset resets
all defaults to factory settings and the language to German and the date, time,
units formats to DD.MM.YYYY, 24 h, m / bar.
Attention:Theuserissolelyresponsiblefortransferredornewlyentered
testcriteria(testsequences,pressuresandtimes)ordefaultsinthe
individualprogramsandtheconclusionsfromthetests.
 Therespectivenationalsafetyprovisions,rulesandregulationsvalidfor
the applicationsitemustbeconsideredandobserved.
Before using the REMS Multi-Push, check whether the respective latest version
software is installed on the input and control unit. Select the Settings menu and
then Device data to display the version software. The latest version software
(Ver. Software) for the input and control unit is available by USB stick as a
download: www.rems.de → Downloads → Software → REMS Multi-Push →
Download. Compare the number of the version software of the unit with the
latest version software number and install the latest version software if neces
-
sary.
Download procedure:
1. Download le
2. Unpack the ZIP le
3. Save "update.bin" on USB stick
4. Plug the USB stick into the USB port of the REMS Multi-Push
REMS Multi-Push must be switched off for this, switch off with the On/Off button
(Fig. 2 (4)) and pull out the mains plug if necessary. Insert the USB stick with
the latest version software into the USB port (Fig. 2 (33)). Plug the mains plug
into the socket. Press the Reset button (Fig. 1 (2)) of the PRCD fault current
circuit breaker (1). The control lamp (5) lights green. The latest version software
is installed. When a USB stick with LED is used, the LED starts ashing. The
installation is nished when the LED no longer ashes. If the USB stick has no
LED, you should wait about 1 minute after switching on the PRCD. The latest
version software is then installed on the input and control unit. Pull out the USB
stick.
Before starting up for the rst time, the language, date and time should be set
in the Settings menu and the defaults for the individual programs checked and
changed if necessary.
If the "?" button (Fig. 2 (7)) is pressed within 5 s after switching on the REMS
Multi-Push, the Settings menu opens. The desired line is selected on the screen
with the arrow buttons ↑ ↓ (8). Displayed values can be changed with the arrow
buttons ← → (11). The value is increased with the arrow pointing to the right
and reduced with the arrow pointing to the left. The values change faster when
the arrow buttons ← → (11) are kept pressed. If more than 5 lines in a subrou
-
tine are occupied, this is displayed by arrows ▼▲ in the top or bottom right
hand corner of the screen respectively. The complete selection of the screen
is conrmed with the Enter button (9) and the next screen appears.
The previous screen appears if the Esc button (10) is pressed during the setting.
Already changed values are rejected.
If the Esc button (10) is pressed during the stabilisation/wait time (t stabi), the
program aborts, the values (useless) are still saved, appear on the screen and
"Cancel" appears additionally on the screen and possibly on the print strip.
If the Esc button (10) is pressed during the test time (t test), the values are still
saved, appear on the screen and "Cancel" appears additionally on the screen
and possibly on the print strip. In the test programs Enter provides a shortcut
for the adaptation of p actual to p refer.
Select language, Enter:
Default German (deu) is preselected. Another language can be selected with
the arrow buttons ← → (11), press Enter.
Select date, Enter:
Format "DD.MM.YYYY" is defaulted for the date. Another format for the date
can be selected with the arrow buttons ← → (11). The next line on the screen
is selected with the arrow buttons ↑ ↓ (8) and the year or month or day can be
selected with the arrow buttons ← → (11). Press Enter.
Select time, Enter:
Default "24 hours" is preselected. Another format for the time can be selected
with the arrow buttons ← → (11). The next line on the screen is selected with
the arrow buttons ↑ ↓ (8) and hours or minutes can be selected with the arrow
buttons ← → (11). Press Enter.
Select defaults \ units, Enter:
Default "m / bar" is preselected. Other units can be selected with the arrow
buttons ← → (11).
Select Defaults \ Defaults \ Leak test with compressed air, Enter:
Check defaults, edit with arrow buttons ↑ ↓ (8) or arrow buttons ← → (11) if
necessary.
19
