9
Software memory requirements
NC1 system software requires approximately 28.0Kb (70 metres) of
part-program memory.
If your controller is short of memory, there is no need to load any of
the subroutines listed below if you do not intend using them:
n
L9862 (tool setting routine) 4.0 Kb (10 metres) of memory.
n
L9863 (broken tool – plunge check) 1.2 Kb (3 metres) of
memory.
n
L9864 (broken tool – radial check) 1 Kb (2.5 metres) of memory.
n
L9865 (checking cutter radii and linear profiles) 4.0 Kb
(10 metres) of memory.
You may also remove the following subroutine after you have finished
running the Beam alignment cycle:
n
L9860 (laser beam alignment routine) 1.5 Kb (3.8 metres) of
memory
Machine tool controllers supported
NC1 system software is suitable for use on the following machine tool
controllers:
n
Siemens 810D
n
Siemens 840D
n
Siemens FMNC
Software memory requirements
