66
The cycle rapids the tool to the measuring height at a depth defined
by the broken tool tolerance value (R11=h input) The tool then moves
in rapid through the beam and is monitored for a broken tool
condition, i.e. the beam is not cut. The radial distance moved by the
tool from the beam centre-line is defined by the R25=y input.
At the end of the cycle, the tool moves out of the beam to the safe
position in the spindle axis only.
CAUTION
1. The latch mode feature of the NC1 system must be
installed and operational if the R25=y input is to be used when
passing the tool through the beam.
2. Before this cycle is called, the tool must be moved to a safe, clear
position in the Z, X, and Y axes. Ensure that the position along the
beam axis to which the tool is moved is safe for radial checking.
Format [R11=h R13=m R19=s R25=y R26=z]
L9864
where [ ] denotes optional inputs
Example R11=5. R13=1. R19=2800 R25=3. R26=6.
L9864
Broken tool detection (radial check)
!
