6
Renishaw NC1 system
Renishaw NC1 tool setting system
This guide describes how to use the Renishaw NC1 non-contact tool
setting system software.
The Renishaw NC1 is a laser-based non-contact tool setting system
that provides high-speed/high-precision measurement of cutting tools
on a machining centre under normal operating conditions.
As a tool is moved through the laser beam, the system detects when
the beam is broken. Output signals sent to the controller allow the
presence of a tool and the position of the tip, a tooth, or a cutting
edge to be established.
The NC1 allows the following parameters to be established:
n
Length and diameter of the cutting tool. Tools as small as 0.2 mm
(0.008 in) diameter can be accurately measured.
n
Detection of a broken tool.
n
Detection of a broken tip or cutting edge, or excessive runout of a
tool.
n
Compensation for thermal changes in the machine tool.
