27
Examples R02=1. R07=100. R06=117. R26=15.
L9860
R02=1. R07=100. R26=15.
L9860
Subroutine inputs
The following inputs are used with this subroutine:
R02=1. Provisional calibration of the system.
Used for checking alignment of the beam and setting
the provisional beam positional data (for details, see
“Parameter store for calibration data” on page 12).
NOTE: When using the R02=1. input, the correct
length of the calibration tool MUST be entered in either
the appropriate tool offset register or as an R06=k
input. By default, the current tool offset length is used
or an alternative tool offset edge (D) can be called by
using the R20=t input).
R02=b (Not used) – beam alignment only.
R06=k k= Reference length of the calibration tool.
Beam alignment
