Packaging, Transport and Installation
20
Fig. 3: Attaching lifting straps
The transportation aid can also be used for lifting the device with a crane.
 Attach the lifting straps to the two transportation aids as shown in the figure.
NOTICE The housing can be damaged if the lifting straps are too short. The four lifting straps
must be sufficiently long in order to observe a minimum distance of 100 cm between the device
and the hoist.
Fig. 4: Minimum distance between housing and hoist
≥ 100 cm
(40 inches)
