Installing additional equipment
71
Example 2
Grinding balls
2 x 15 mm steel grinding balls
Sample material
Dried plant parts,
approx. 50 % of the filling
quantity of the vessel
9.2 Adapter for 4 x 5 ml steel grinding jars
The device can be equipped with an adapter for 4 x 5 ml steel grinding jars for the grinding
process. The adapter enables simultaneous grinding of up to 8 samples.
Mount the adapter as follows:
NOTICEAlways load the adapter in a symmetrical arrangement. Failure to do so may result in
damage to the device and uneven grinding process due to theimproper loading.
Insert the reaction vials into the adapter with the bottom first.
Screw the lid onto the adapter.
Open the grinding jar holder as described in the previous chapters.
Insert the adapter into the opened grinding jar support.
Close the grinding jar support as described in the previous chapters.
Start the grinding process with the required parameters.
Abb. 42:Adapter for 4 x 5 ml steel grinding jars in the grinding jar support
Abb. 43:Permissible arrangement of the steel grinding jars in the adapter
