ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 42
Model:
Displays the type of Alarm Module.
Serial Number:
Displays the Alarm Module’s Serial Number.
Firmware Version:
Displays the Alarm Module’s Firmware Version.
Hardware Revision:
Displays the Alarm Module’s Hardware Revision.
External Alarm Input:
Displays the four (4) configurable external temperature/analogue/digital inputs.
Input ID:
The name assigned for the respective External Input.
Status:
Indicates the current status of the four (4) External Alarm Inputs.
Digital Input:
Displays the ten (10) configurable digital inputs.
Input ID:
A label for the respective Digital Input.
Function:
Indicates the selected input mode for each of the ten (10) Digital Inputs.
Status:
Indicates the current status of the four (4) External Alarm Inputs.
