ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 46
Alarm Output:
Displays the ten (10) configurable relay outputs.
Port:
Displays the Tx Port that the Alarm Output is currently associated to.
Channel:
Displays the Tx Channel that the Alarm Output is currently associated to.
Status:
Indicates the current status of the ten (10) Alarm Outputs.
Refresh:
Reloads the page, updating the status information.
Note: The field behind an alarm is highlighted in colour to indicate its current status.
Green denotes ‘no alarm’, and Red denotes ‘alarm’.
Note: The “Status – Alarm Modules” menu item under the Status menu appears only if one or more (optional) Channel Alarm
Modules (CAM) or Site Alarm Modules (SAM) are installed. Up to ten (10) CAM/SAM units may be fitted to each ASM as
required.
