ASMxxxx Series User’s Manual
Asia Pacific | EMEA | Americas 80
Defaults:
Clicking this resets all data fields to the factory defaults. The default settings are;
RxA-IN to Rx-Out Gain 15dB
RxB-IN to Rx-Out Gain 15dB
External Antenna RxE-IN to Rx-Out Gain 15dB
RxA-IN to RxA-OUT Checked
RxB-IN to RxB-OUT Checked
Discard Changes:
Click this button to restore the values to those current saved. Note that if invalid values are being displayed after an Apply
attempt, these values may not match the current system configuration. In this case, just select the Configure - Receive Systems
Module menu item again to re-display the current configuration.
Save:
This will attempt to save and activate the values entered. If any out of range values are present, nothing will be saved and the
problem settings will be highlighted with a red background.
