Ricoh Aficio SP 3410DN Hardware Guide

When Paper is Jammed
93
8
H With the duplex transport unit still lowered, carefully slide tray 1 back in
until it stops.
I If paper is loaded in the bypass tray, remove the paper and close the bypass
tray.
J Push the side button to open the front cover, and then carefully lower it.
K Carefully pull out the print cartridge horizontally, holding its center.
• Do not shake the removed print cartridge. Doing so can cause remaining
toner to leak.
• Place the print cartridge on paper or similar material to avoid dirtying
your workspace.
BXG040
BXG057
BXG058

Ricoh Aficio SP 3410DN Specifications

General

Print Technology	Laser
Paper Capacity	250 sheets
Connectivity	USB 2.0, Ethernet
Memory	128 MB
First Print Out Time	8 seconds
Maximum Paper Size	A4
Resolution	1200 x 600 dpi
Duplex Printing	Yes
Paper Input	250-sheet tray, 50-sheet bypass tray
Supported Paper Sizes	A4, A5, A6, B5, Letter, Legal
Dimensions	370 x 392 x 262 mm
Operating System Compatibility	Windows, Mac, Linux
