Ricoh Aficio SP C320DN User Manual

2. Remove the memory cover.
CBK057
3. Loosen the screw securing the inner cover by using a coin.
CBK058
4. Be sure to install the hard disk as shown.
CBK247
5. Align the connector of the hard disk ( ) with the connector on the board of the printer
( ), and then carefully push in the hard disk until it can go no further.
If tightening the screw is difficult, loosen the screw, adjust its position, and then try tightening it again.
Installing the Memory Expansion Units
55
3

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
