Ricoh Aficio SP C320DN User Manual

1. Check the contents of the package.
BFL302S
2. Turn off the power, and then unplug the power cord.
3. Remove the cable cover.
CBK233
4. Remove the two screws and remove the cover of the slot in which the 1284 interface board
is installed.
The removed cover is not used when the 1284 interface board is installed.
CBK255
Installing the Interface Units
63
3

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
