Ricoh Aficio SP C320DN User Manual

5. Fully insert the IEEE 1284 interface board.
CBK082
6. Tighten the two screws to secure the interface board.
Check the IEEE 1284 interface board is connected firmly to the interface board slot.
CBK083
• Confirm that the IEEE 1284 interface board was correctly installed by printing the configuration page.
If it is correctly installed, "Parallel Interface" will appear for "Device Connection" on the configuration
page.
• If the board was not installed properly, repeat the procedure from step 4. If it cannot be installed
correctly even after reattempting installation, contact your sales or service representative.
• For details about printing the configuration page, see "Test Printing".
• p.43 "Test Printing"
3. Installing Options
64
3

Ricoh Aficio SP C320DN Specifications

General

Print Technology	Laser
Duplex Printing	Yes
Processor	400 MHz
Supported Operating Systems	Windows, Mac OS, Linux
Resolution	1200 x 1200 dpi
Connectivity	USB 2.0, Ethernet
Memory	128 MB (expandable to 640 MB)
Dimensions	400 x 428 x 368 mm
Print Speed	Up to 26 ppm
Monthly Duty Cycle	Up to 50, 000 pages
