1.Installation
14
3. Release the latches and remove the standard 2GB DIMM [A].
4. Insert the 4GB DIMM into SDRAM socket.
Push the release latches [A] until they slip into the notch on the edge of the SDRAM.
5. Reattach the controller box cover and rear cover.
Connecting the E-25C to Copier
1. Remove the slot cover [A].
To Next Page
