PAPER FEED UNIT (OPTIONAL) 30 November, 1999
6-24
6.10.3 CONNECTOR
A: Connector (2 clips)
NOTE: When installing the connector [A], the side with the small hole must
face the outside of the machine.
H545R503.WMF
[A]
