2. Insert the paper with the side you want to copy facing down, and then adjust the paper
guide with the paper size.
CUA109
1
1
2
3
2
3
4
4
1. Horizontal size
2.
Vertical size
3. Extender
4. Paper guides
The bypass tray is selected on the display.
• If the guides are not flush against the copy paper, images might be skewed or paper misfeeds
might occur.
•
Load only as much paper as can be held between the guides on the bypass tray.
Overloading the bypass tray can result in misfeeds and skewed images.
• Pull the extender out to support paper sizes larger than A4
, 8
1
/
2
" × 11" .
•
Fan paper to get air between the sheets and avoid a multi-sheet feed.
• If [Byp.] is not selected on the display, select [Byp.] using the [
] or [ ] key, and then press
the [ ] key.
3. Press the [ ] key, and then select the paper size and type.
When copying onto regular size paper
1.
Select [Paper Size] using the [
] or [ ] key, and then press the [OK] key.
2. Copying
46

Ricoh MP 2001L Specifications

General

Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Maximum Paper Size	A3
Paper Output Capacity	250 sheets
Power Source	220 - 240V, 50/60Hz
Color	Monochrome
Copy Magnification	25% - 400%
Print Speed	20 ppm
Memory	128 MB
Type	Digital
Power Consumption	1.2 kW
