1. ADF's extender
Pull this extender to support large paper.
2. Vents
Prevent overheating.
3. Extender for the bypass tray
Pull this extender out when loading A4 , 8
1
/
2
× 11 or larger size paper in the bypass tray.
4. Bypass tray
For details about the sizes and types of paper that can be used, see page 140 "Loading Paper into the
Bypass Tray".
5. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
6. Front Cover
Open to access the inside of the machine and remove jammed paper.
Open here to replace the print cartridge.
Rear and left view
1. Vents
Prevent overheating.
Guide to Names and Functions of Components
29
