Ricoh Printer Quick Installation Guide

Using the Envelope Lever
• The inside of the machine becomes very hot. Do not touch the parts with a " " label (means
hot surface). Touching a part with a " " label (means hot surface) could result in a burn.
• The fusing unit becomes very hot. When installing the new fusing unit, turn off the printer and
wait about an hour. After that, install the new fusing unit. Not waiting for the unit to cool down
can result in a burn.
1. Open the rear cover.
BMU034S
2. If the optional duplex unit is attached, push down the lever on the right side of the duplex
unit ( ), and then pull it out until it stops ( ).
BMU077S
Using the Envelope Lever
179
9
