01: Machine: Image Position

0101: Perpendicularity Adjustment

Correct the perpendicularity of image.

Setting Item

Default

Value

Max.

Value

Min.

Value

Step Unit

01: [Correction Value] 0 20 -20 1 pulse

5. Adjustment Settings for Operators

200
