Ricoh Pro C7500 - Loading Paper on the Multi Bypass Banner Sheet Tray

M0EBIM2121
1
2
2
1. Tab fence
2. Fence
Loading Paper on the Multi Bypass Banner Sheet Tray
When the Multi bypass banner sheet tray is attached to the machine, you can load paper that is 487.8
mm–1260.0 mm (19.2–49.6 inches) long horizontally on the tray (Tray A).
1. Remove the fence.
To remove the fence, slide it to the right while pressing down on the stopper.
M0EDIM0131
2. Set the fences against the paper, and then square the paper and load it print side up.
Do not stack paper over the upper limit mark.
Loading Paper into the Paper Tray
79
